Case Study: Hilton Garden Inn – Room Control Unit (RCU) Solution

We have successfully implemented Systemteq-based RCU (Room Control Unit) solutions that fully comply with international hotel standards, delivering superior comfort, service quality, and energy efficiency.

Project Objective

Provide hotel operations with a standardized, high-performance guest room control system — including equipment configuration, smart panels, and control software — for easy introduction, promotion, and consistent service delivery.

System Overview & Functions

Our RCU system is designed to deliver comprehensive room services while strictly following Hilton Garden Inn specifications:

• Intelligent Control
  Automated management of lighting, sockets, air conditioning, curtains, and in-room devices to ensure maximum guest comfort and convenience.
  – Wall Controller Priority: Guests can manually adjust temperature, fan speed, and operation mode anytime.
  – Automatic Control: System takes over to optimize settings when rooms are unoccupied or based on schedule.
• Networking & Integration
  – Connected seamlessly to Hotel PMS (Property Management System) for check-in/check-out synchronization.
  – Stable Ethernet-based communication between all modules, floor servers, and central control.
  – Fully certified and compatible with standard hotel management software.
• Power Management
  – Controlled Circuits: Lighting, AC, and general sockets are automatically powered down or set to low-power mode when the room is vacant.
  – Uncontrolled Circuits: Critical devices (shaver socket, mini-fridge, alarm clock, set-top box, dedicated desk power) remain always-on for guest convenience.
• Lighting Control System
  – Supports standard switch control and scene control (Welcome, Bright, Soft, Sleep modes).
  – Dimming Capability:
  Standard Rooms: ≥1 circuit with dimming module.
  Suites (<3 rooms): ≥4 circuits.
  Suites (≥3 rooms): ≥8 circuits.
  – Relay Specifications: Minimum 10A capacity; uses high-quality brands: Siemens / Omron.
  – Power Reserve: All circuits designed with 20% power surplus for safety and expansion.
• Air Conditioning & Energy Saving Mode
  – Dual Control: Guest panel + System automatic regulation.
  – Smart Dehumidification: Activates automatically at humidity ≥70–80% (setpoint 27°C) to maintain air quality while saving energy.
  – Unoccupied Mode: Automatically raises setpoint and reduces fan speed when no presence is detected — cutting consumption significantly.
• Occupancy Detection & Power Saving
  – Card-Free Power Retrieval: Uses door magnetic sensors + high-precision infrared detectors (accuracy ≥99.5%).
  – Logic Operation:
  When guest enters → Power ON automatically.
  When guest leaves → Delayed shut-off / switch to energy-saving mode.
  Silent components: Contactors and sensors designed for noiseless operation.
• Scene & Welcome Modes
  – Welcome Mode: Gradual lighting activation, automatic curtain opening, and TV power-on upon entry — creating a warm atmosphere.
  – Custom Scenes: One-touch control for preset environments (Reading, Relax, Sleep, Cleaning).

Systemteq Hardware Specifications

All modules are CE-certified, built for stability, and designed for easy installation and expansion:

1. Main Control Module – SWD-GW100
   Central brain of the system; coordinates all modules, sensors, and communication.
   Processes data, executes logic rules, and ensures synchronization with hotel systems.
2. 0–10V Dimming Module – SWD-PVM410
   Precise voltage regulation for smooth lighting dimming.
   Optimizes power output and extends lamp lifespan.
3. Multifunctional Module – SWD-SQ167
   6-way relay output for controlling curtains, HVAC valves, motors, and other actuators.
   Flexible logic programming for various room configurations.
4. Sensors & Peripherals
   – Infrared Occupancy Sensor: Detects human presence with high accuracy.
   – Door Magnetic Sensor: Monitors door open/close status.
   – Temperature & Humidity Sensor: Enables climate-based automation.
   – Smart Panels:Material: PC / Dark gray / Matte finish / Frameless design.
   – Backlight: Gradient color options for modern aesthetics.
   – Buttons: Customizable labeling and functions.

Why Choose Systemteq?

• Proven Technology: Deployed in international hotel chains and commercial buildings.
• Compliance: Fully meets Hilton Garden Inn and global industry standards.
• Measurable ROI: Fast payback period through consistent energy savings.
• Full Service: From assessment, design, installation, training, to long-term maintenance.
• Local Support: Indonesian-based team with international expertise.
